華為交換機console密碼設置,恢復出廠設置,poe交換機關閉poe技巧

發布時間:2025-04-02 文章來源:xp下載站 瀏覽:

路由器(Router)是連接兩個或多個網絡的硬件設備,在網絡間起網關的作用,是讀取每一個數據包中的地址然后決定如何傳送的專用智能性的網絡設備,路由器最主要的功能為實現信息的轉送。

一、華為交換機設置console口密碼:

華為交換機console密碼配置,恢復出廠配置,poe交換機關閉poe功能

<Amet-NJ-SW-01>system-view//進系統視圖

[Amet-NJ-SW-01]user-interface console 0//進入console 0口(就一個console口,默認為0口)

[Amet-NJ-SW-01-ui-console0]authentication-mode password//啟用密碼認證

[Amet-NJ-SW-01-ui-console0]set authentication password cipher Aa123456//設置終端登錄密碼

[Amet-NJ-SW-01-ui-console0]quit

Dec 24 2021 15:20:17 Amet-NJ-SW-01 DS/4/DATASYNC_CFGCHANGE:OID 1.3.6.1.4.1.2011.5.25.191.3.1 configurations have been changed.The current change number is 2,the change loop count is 0,and the maximum number of records is 4095.

[Amet-NJ-SW-01-ui-console0]quit

[Amet-NJ-SW-01]quit

<Amet-NJ-SW-01>

二、華為交換機恢復出廠配置

<Amet-NJ-SW-01>reset factory-configuration

Warning:The command will delete all the configurations and files

except the startup,patch,module,and license files

from the device.Continue?[Y/N]:y

Warning:The system will reboot after configurations and files are deleted.Continue?[Y/N]:y

Info:Start restoring factory configurations.Please wait....

Info:This operation will take several seconds.Please wait.....

三、華為交換機默認登錄用戶名和密碼

Username:admin

Password:admin huawei.com

或者是Admin huawei.com

四、華為路由器破解密碼

Enter auto startup

try to start bootloader menu:start_kernel_from_flash

startup from master kernel

Allocating memory for ELF segment:addr:0xffffffff80800000

adjusted to:0x800000

,size 0xcbb4f0

##Loading big-endian Linux kernel with entry point:0xffffffff80fd06f0...

Bootloader:Done loading app on coremask:

0x3f

Starting cores:

0x3f

INIT:version 2.88 booting

Starting udev

-n Starting Bootlog daemon:

bootlogd.

sh:201711260815:out of range

Enter bootloader v7.1

CPLD userspace init ok

Initializing i2c bus

Initializing clock success 0

Setting console

Press Ctrl+B to break auto startup...2

config IP address:ifconfig eth2 192.168.1.8

Enter Password:******

Enter Password:************

Default Password,Please Set New Password.

BootLoader Menu

1.Default Startup

2.Serial Menu

3.Network Menu

4.Startup Select

5.File Manager

6.Reboot

7.Password Manager

Enter your choice

1-7

:7

PassWord Menu

1.Modify the menu password

2.Clear the console login password

0.Return

Enter your choice

0-2

:2

Clear the console login password Succeed!

PassWord Menu

1.Modify the menu password

2.Clear the console login password

0.Return

Enter your choice

0-2

:1

Modify password.the password length must>=6.Press Ctrl+c to break.

Enter Old Password:************

Input new password:********

Input new password again:********

Are you sure to change password?[y/n]:y也可以修改破解密碼的默認密碼。這里也可以不更改。

Save new password Success.

PassWord Menu

1.Modify the menu password

2.Clear the console login password

0.Return

Enter your choice

0-2

:0

BootLoader Menu

1.Default Startup

2.Serial Menu

3.Network Menu

4.Startup Select

5.File Manager

6.Reboot

7.Password Manager

-n Stopping syslogd/klogd::6

no syslogd found;none killed

Unmounting remote filesystems...

Unmounting local filesystems...

-n Rebooting...

Restarting system.

Warning:chips select 0 property cavium,t-wait,clocks 301,clock time 300,period 1000,mult:1 exceeds maximum value 63,truncating.

五、華為Poe交換機關閉POE功能,進入接口,關閉接口POE功能

[poe-swtich]interface range GigabitEthernet 0/0/9 to GigabitEthernet 0/0/49

[poe-swtich-port-group]und

[poe-swtich-port-group]undo poe en

[poe-swtich-port-group]undo poe enable

[poe-swtich-GigabitEthernet0/0/9]undo poe enable

[poe-swtich-GigabitEthernet0/0/10]undo poe enable

[poe-swtich-GigabitEthernet0/0/11]undo poe enable

[poe-swtich-GigabitEthernet0/0/12]undo poe enable

[poe-swtich-GigabitEthernet0/0/13]undo poe enable

[poe-swtich-GigabitEthernet0/0/14]undo poe enable

[poe-swtich-GigabitEthernet0/0/15]undo poe enable

[poe-swtich-GigabitEthernet0/0/16]undo poe enable

[poe-swtich-GigabitEthernet0/0/17]undo poe enable


本文可以幫助您基本地設置和管理您的路由器。
